APRILIA RSV4 R User Manual

520.0 +/- 2.5 cm³ (31.73 +/- 1.15 cu.in) (for each
stem)
Reassembling the fork
•
Lock the stem in a vice without dam-
aging the surface.
•
Protect the bearing tube end with ad-
hesive tape.
•
Lubricate the sliding edges with fork oil
or sealing grease.
•
Fit on the slider the dust scraper, the
retainer ring and the seal ring.
•
The sealing ring must be placed with
the stamped part facing the dust gaiter.
RSV4 R Suspensions
SUSP - 375
