1. Side stand sensor
2. Fuel pump
3. Instrument panel
4. Left hand switch
5. Right hand switch
6. Water Temperature Sensor
7. Cooling fans
8. Upper injectors
9. Air temperature sensor
10.Starter motor
11.Lower injectors
12.Air pressure sensor
13.Exhaust valve
14.Lambda probe
15.Speed sensor
16.Headlamp
17.Rear turn indicators
18.Fall sensor
19.Horn
20.Voltage regulator
21.Battery
22.Seconday fuses
23.Control unit
24.Hand grip position sensor
25.Oil pressure sensor
26.Alternator
27.Coils
28.Timing sensor
A RELAY CANNOT BE IDENTIFIED BASED ON THE FOLLOWING INDICATIONS ONLY: THIS HAS
TO BE DONE ALSO IDENTIFYING THE COLOUR OF THE RELAY CABLES.
RELAY LAYOUT
Component position
in the electrical circuit
diagram
Component name Location on the vehicle
10 Low-beam light relay Windshield front part
9 High-beam light relay Windshield front part
31 Start-up relay Rear undertail section
19 Protection relay Under the saddle next to the battery, left side
33 Injection relay Under the saddle next to the battery, right side
36 Fan control relay In the niche of the headstock, on the left
RSV4 R Electrical system
ELE SYS - 95
