APRILIA RSV4 R User Manual

Flywheel cover installation
•
Insert the centring dowels in the cover.
•
Apply a layer of sealing paste along the
external edge of the cover.
•
Insert the cover together with the sta-
tor.
Recommended products
Three bond Sealing paste
-
•
Turn the five screws (1) and the two
screws (2).
•
Tighten the screws working in stages
and diagonally.
•
Insert the Blow-by system pipe and
fasten it with a new clamp.
Engine RSV4 R
ENG - 260

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
