TABLE K1 - PINION CASING AREA

46. Gear sensor cable harness routing

47. Oxygen sensor connector on the vehicle cable

harness

48. Gear sensor

49. Oxygen sensor connector

50. Stand switch cable harness routing

51. Oxygen sensor cable harness routing

52. Clamp

53. Stand switch

54. Oxygen sensor

55. Mounting

TABLE K2

Pass the cable harnesses behind the cable

grommet that closes the two fuel breather

pipes.

56. Oxygen sensor cable harness routing

57. Gear sensor cable harness routing

58. Stand switch cable harness routing

TABLE L

59. Cable guide

60. Oxygen sensor cable harness routing

61. Stand switch cable harness routing

Electrical system RSV4 R

ELE SYS - 112
