APRILIA RSV4 R User Manual

•
Ease off the side fairing, taking partic-
ular care not to damage the fitting with
the lower side fairing and the tabs fas-
tening the side fairing to the lug.
•
Release the insert on the retainer with
the duct.
•
Release the three inserts on the inner
fairing.
•
To refit, repeat the above procedure in reverse order, taking particular care not to damage
the components involved.
NOTE
HANDLE PAINTED AND PLASTIC COMPONENTS WITH CARE; BE CAREFUL NOT TO SCRATCH
OR DAMAGE THEM.
RSV4 R Bodywork
BODYW - 455
