C: Track C signal
•
D: Track D supply
•
E: Track D ground
•
F: Track D signal
DIAGNOSIS INSTRUMENT: PARAMETERS
Blue lower connector throttle grip position sensor - track A
•
Example value with key ON: 1107 mV
•
Example value with engine on: -
Voltage value of the lower potentiometer - track A
Blue lower connector throttle grip position sensor - track B
•
Example value with key ON: 1070 mV
•
Example value with engine on: -
Voltage value times 2 of the lower potentiometer track B
White upper connector throttle grip position sensor - track C
•
Example value with key ON: 3560 mV
•
Example value with engine on: -
Voltage value of the upper potentiometer track C
White upper connector throttle grip position sensor - track D
•
Example value with key ON: 3555 mV
•
Example value with engine on: -
Voltage value times 2 of the upper potentiometer track D
Throttle grip position sensor
•
Example value with key ON: 1107 mV
•
Example value with engine on: -
Voltage corresponding to the potentiometer track A
Throttle grip opening percentage
•
Example value with key ON: 0 mV
•
Example value with engine on: -
With a released throttle grip, the value read should be 0%, whereas 100 % should be read with throttle
grip fully twisted.
DIAGNOSIS INSTRUMENT: STATUSES
Throttle grip
•
Slightly twisted_choked_fully twisted
Throttle grip self-acquisition
•
carried out/not carried out
CAUTION
RSV4 R Electrical system
ELE SYS - 157
