APRILIA RSV4 R User Manual

•
Loosen the drive chain adjuster
screws.
•
Loosen the rear wheel fixing nut.
•
Remove the pinion, releasing it from
the drive chain.
•
Remove the side stand.
•
Remove the two fuel breather pipes
•
Detach the neutral sensor.
See also
Side
stand
RSV4 R Engine from vehicle
ENG VE - 229

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
