APRILIA RSV4 R User Manual

•
Position the special tool from the alter-
nator side in order to not ruin the edges
of the oil seal.
•
Insert the gearbox unit in the crank-
case.
Specific tooling
0277308 Guide bushing for secondary gearbox
shaft
•
Remove the special tool from the alter-
nator side.
•
Tighten the six screws that fasten the
gearbox unit to the crankcase.
Specific tooling
0277308 Guide bushing for secondary gearbox
shaft
Engine RSV4 R
ENG - 252

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
