Compress the valve springs with the

specific wrench and with the spring

compressing tool.

•

Insert the cotters into the seat

Specific tooling

AP8140179 Valve spring compressor

020853Y Intake valve spring compressor

020854Y Exhaust valve spring compressor

•

Release the wrench, checking that the

cotters are positioned correctly in the

valve grooves.

•

Position the adjustment shims and

then the bucket tappets.

RSV4 R Engine

ENG - 313

Questions and Answers:

Need help?

Do you have a question about the APRILIA RSV4 R and is the answer not in the manual?

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
