Spread grease on the sliding surfaces
of the bushing on the special tool.
•
Install the new bushing, aligning the
hole with the slot on the ring of the spe-
cial tool.
•
Place the ring on which the bushing is
installed onto the special tool's punch.
•
Place the adaptor (3) on the ring for
centring the bushing.
•
Place the punch in the crankcase,
aligning the slot on the ring of the spe-
cial tool with the reference marked on
the crankcase exterior.
•
Use the press to install the new bush-
ing.
•
Remove the special tool.
•
Use a thin screwdriver to check that the
countershaft lubrication oil passage is
aligned with the hole on the installed
bushing.
Engine RSV4 R
ENG - 332

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
