Insert the retainer ring in its position.
•
Fit the oil seal with the specific tool.
Specific tooling
8140145 Fitting tool for Ø 41 mm (1.61 in) seal-
ing ring
8140146 Weight to be applied to the tool:
8140145
•
Fit the centring bushing on the car-
tridge and insert the whole assembly in
the fork.
•
Tighten the screw fixing the pumping
member on the fork end to the prescri-
bed torque.
RSV4 R Suspensions
SUSP - 377

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
