APRILIA RSV4 R User Manual

•
Remove the left bearing (18) with the
specific extractor.
•
Collect the inside spacer (19).
•
Remove the right bearing (20) with the
specific extractor.
•
Retrieve the right hand spacer (21).
•
Clean the inside of the hub thoroughly.
CAUTION
WASH ALL THE PARTS WITH CLEAN DETERGENT.
Specific tooling
AP8140180 Extractor for bushings
Suspensions RSV4 R
SUSP - 392

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
