APRILIA RSV4 R User Manual

OIL RADIATOR
pos. Description Type Quantity Torque Notes
1 Screws fastening oil radiator to
mounting bracket
M6 1 7 Nm (5.16 lbf ft) -
Removing
•
Drain the engine oil.
•
Remove both fairings and the radiator
cowl.
•
Release the clamp and disconnect the
right hand radiator pipe.
•
Release the clamp and disconnect the
left hand radiator pipe.
See also
Replacement
•
Remove the split pin.
•
From the opposite site, remove the
coolant radiator-oil radiator connector
pin.
Chassis RSV4 R
CHAS - 418
