APRILIA RSV4 R User Manual

TAIL
pos.
Description Type Quantity Torque Notes
1 Rear screws fastening tail fairing to
taillight bracket
M5 2 3 Nm (2.21 lbf ft) -
2 Screws fastening the saddle cover
base to the saddle cover
SWP 2.9 3 1 Nm (0.74 lbf ft) -
3 Saddle cover pin fixing screws M4 1 1.5 Nm (1.11 lbf ft) -
4 Screws fastening grilles to tail fairing M5 2 0.5 Nm (0.37 lbf ft) -
5 Screws fastening side fairings to tail
fairing
M5 2 1 Nm (0.74 lbf ft) -
6 Screws fixing side fairings to tank M5 2 + 2 2 Nm (1.47 lbf ft) -
7 Screws fastening tail fairing to saddle
mounting
M5 2 3 Nm (2.21 lbf ft) -
8 Screws fastening tail fairing to saddle
mounting bracket
M5 2 2 Nm (1.47 lbf ft) -
9 Screws fixing tail fairing to lower sad-
dle mounting fastener
M5 2 3 Nm (2.21 lbf ft) -
RSV4 R Bodywork
BODYW - 447

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
