APRILIA RSV4 R User Manual

FRONT ELECTRICAL SYSTEM
pos.
Description Type Quantity Torque Notes
1 Fall sensor mounting fixing screw M6 1 8 Nm (5.9 lbf ft) -
2 Horn fixing screw M8 1 15 Nm (11.06 lbf ft) -
3 Screw fastening the voltage regula-
tor to the inner fairing
M6 2 6 Nm (4.42 lbf ft) -
4 Shear head screw (to the left of the
ignition lock)
M8 1 Manual Tighten until the
head shears off
5 Right hand ignition lock screw M8 1 20 Nm (14.75 lbf ft) -
RSV4 R Electrical system
ELE SYS - 93

APRILIA RSV4 R Specifications

General

Displacement	999.6 cc
Torque	115 Nm @ 10, 000 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Seat Height	845 mm
Dry Weight	179 kg
Bore x Stroke	78 x 52.3 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Wheelbase	1420 mm
Power	180 hp @ 12, 500 rpm
Front Suspension	Upside-down fork, 43 mm
Front Brakes	Dual 320 mm discs, radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel System	Fuel injection
Fuel Capacity	18.5 L (4.9 US gal)
