User's Manual 1004 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
3fd61009 0e2f3cc5
(4923 30) h323-disconnect-cause = 22 (0x16)
(4923 27) h323-call-type = VOIP
(4923 26) h323-call-origin = Originate
(4923 24) h323-conf-id = 02102944 600a1899 3fd61009 0e2f3cc5
63.4 Querying Device Channel Resources using SIP
OPTIONS
The device reports its maximum and available channel resources in SIP 200 OK responses
upon receipt of SIP OPTIONS messages. The device sends this information in the SIP X-
Resources header with the following parameters:
telchs: Specifies the total telephone channels and the number of free (available)
telephone channels.
mediachs: Not applicable.
Below is an example of the X-Resources:
X-Resources: telchs= 12/4;mediachs=0/0
In the example above, "telchs" specifies the number of available channels and the number
of occupied channels (4 channels are occupied and 12 channels are available).
Note: This feature is applicable only to the Gateway application.
