AudioCodes Mediant 800B User Manual

Version 7.2 897 Mediant 800B Gateway & E-SBC
User's Manual 52. USB Storage Capabilities
52 USB Storage Capabilities
The device supports USB storage using an external USB hard drive or flash disk (disk on
key) connected to its USB port. The storage capabilities are configured using the CLI and
include the following:

To save network captures to the USB:
# debug capture data physical stop usb

To update the device's firmware from the USB:
# copy firmware from usb:///<cmp file name>

To update the device's configuration from the USB:
# copy voice-configuration from usb:///<ini configuration file
name>

To save the current configuration to the USB:
# copy voice-configuration to usb:///<ini configuration file
name>
Note: Only a single USB storage (formatted to FAT/FAT32) operation is supported
at any given time.
