User's Manual 1018 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
ITU Perceived Severity
(SNMP Alarm’s Severity)
AudioCodes' Syslog Severity
Indeterminate
Notice
Cleared
Notice
Cleared Alarms: CLEAR-ALARM: <Alarm Name>; Textual Description: <Textual
Description>;
Severity <Alarm Sev
erity>; Source <Al
arm Source>;
Unique ID: <Alarm
Unique ID >; If exists Additional Info1:/ Additional Info2:/ Additional Info3:
64.2.2 Enabling Syslog
The following procedure describes how to enable Syslog.
To enable Syslog:
1. Open the Syslog Settings page (Troubleshoot menu > Troubleshoot tab > Logging
folder > Syslog Settings).
2. From the 'Enable Syslog' drop-down list, select Enable.
Figure 64-2: Enabling Syslog
3. Click Apply.
64.2.3 Configuring the Syslog Server Address
The following procedure describes how to configure the Syslog server's address to where
the device sends Syslog messages.
To configure the Syslog server address:
1. Open the Syslog Settings page (Troubleshoot menu > Troubleshoot tab > Logging
folder > Syslog Settings).
2. In the 'Syslog Server IP' field (SyslogServerIP), enter the IP address of the Syslog
server.
3. In the 'Syslog Server Port' field, enter the port of the Syslog server.
Figure 64-3: Configuring the Syslog Server Address
4. Click Apply.
64.2.4 Configuring Syslog Debug Level
You can configure the amount of information (debug level) to include in Syslog messages.
You can also enable the device to send multiple Syslog messages bundled into a single
packet, and enable a protection mechanism that automatically lowers the debug level when
the device's CPU resources become low, ensuring sufficient CPU resources are available
for processing voice traffic.
