AudioCodes Mediant 800B User Manual

User's Manual 848 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
Note: The 'Enable User-Information Usage' parameter appears in the Web interface
only if the device's License Key is defined with far-end users.
4. Reset the device with a save-to-flash for your settings to take effect; the User Info
table now appears in the Web interface.
47.7.2 Gateway User Information for PBX Extensions and "Global"
Numbers
The GW User Info table contains user information that can be used for the following
Gateway-related features:
 Mapping (Manipulating) PBX Extension Numbers with Global Phone Numbers:
maps PBX extension number, connected to the device, with any "global" phone
number (alphanumerical) for the IP side. In this context, the "global" phone number
serves as a routing identifier for calls in the "IP world" and the PBX extension uses this
mapping to emulate the behavior of an IP phone. This feature is especially useful in
scenarios where unique or non-consecutive number translation per PBX is needed.
This number manipulation feature supports the following call directions:
• IP-to-Tel Calls: Maps the called "global" number (in the Request-URI user part) to
the PBX extension number. For example, if the device receives an IP call
destined for "global" number 638002, it changes this called number to the PBX
extension number 402, and then sends the call to the PBX extension on the Tel
side.
Note: If you have configured regular IP-to-Tel manipulation rules (see 'Configuring
Source/Destination Number Manipulation' on page 555), the device applies these
rules before applying the mapping rules of the User Info table.
• Tel-to-IP Calls: Maps the calling (source) PBX extension to the "global" number.
For example, if the device receives a Tel call from PBX extension 402, it changes
this calling number to 638002, and then sends call to the IP side with this calling
number. In addition to the "global" phone number, the display name (caller ID)
configured for the PBX user in the User Info table is used in the SIP From header.
Note: If you have configured regular Tel-to-IP manipulation rules (see 'Configuring
Source/Destination Number Manipulation' on page 555), the device applies these
rules before applying the mapping rules of the User Info table.
 Registering Users: The device can register each PBX user configured in the User
Info table. For each user, the device sends a SIP REGISTER to an external IP-based
Registrar server, using the "global" number in the From/To headers. If authentication
is necessary for registration, the device sends the user's username and password,
configured in the User Info table, in the SIP MD5 Authorization header.
You can configure up to 500 mapping rules in the GW User Info table. These rules can be
configured using any of the following methods:
 Web interface - see 'Configuring GW User Info Table through Web Interface' on page
849
 CLI - see Configuring GW User Info Table through CLI on page 851
