User's Manual 918 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
Parameter Description
Board Type
Product name of the device.
Device Up Time
Duration that the device has been up and running since the
last reset. The duration is displayed in the following format:
dd:hh:mm:ss:100th of a second
Device Administrative State
Administrative status ("Unlocked" or "Locked"), as performed
in Locking and Unlocking the Device on page 823.
Device Operational State
Operational status:
"Disabled"
"Enabled"
"Error"
"Unknown"
Flash Size [Mbytes]
Size of the non-volatile storage memory (flash), measured in
megabytes.
RAM Size [Mbytes]
Size of the random access memory (RAM), measured in
megabytes.
CPU Speed [MHz]
Clock speed of the CPU, measured in megahertz (MHz).
Versions
Version ID
Software version number.
DSP Type
Type of DSP.
DSP Software Version
DSP software version.
DSP Software Name
DSP software name.
Flash Version
Flash memory version number.
Loaded Files: Displays installed Auxiliary files. You can also delete a file, by clicking the
corresponding Delete button, as described in Deleting Auxiliary Files on page 833.
55.2 Viewing Device Status on Monitor Page
The Web interface's Monitor page provides basic status and information on the device. The
page is useful in that it allows you to easily obtain an overview of the device's operating
status at a single glance.
To view device status and information on the Monitor home page:
On the Menu bar, click Monitor or if you are already in the Monitor menu's Navigation
tree, click Monitor.
The Monitor page displays the following groups of information:
Device Information pane:
'Address': IP address of the device's OAMP interface
'Firmware': Software version currently running on the device
'Type': Name of the device
'HA Status': High-Availability (HA) status of the device, if configured for HA. For
more information, see Viewing HA Status on Monitor Web Page on page 805.
