AudioCodes Mediant 800B User Manual

User's Manual 152 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
Index
Application
Type
Interface
Mode
IP Address
Prefix
Length
Default
Gateway
Ethernet
Device
Name
0 OAMP IPv4
Manual
192.168.0.2 16 192.168.0.1 1 ManagementIF
1 Control IPv4
Manual
200.200.85.14 24 200.200.85.1 200 myControlIF
2 Media IPv4
Manual
211.211.85.14 24 211.211.85.1 211 myMediaIF
2. Static Routes table: A routing rule is required to allow remote management from a
host in 176.85.49.0 / 24:
Table 12-9: Example Static Routes Table
Destination Prefix Length Gateway
176.85.49.0 24 192.168.11.1
3. All other parameters are set to their respective default values. The NTP application
remains with its default application types.
12.5.3.3 VoIP Interfaces for Combined Application Types
This example describes the configuration of multiple interfaces for the following
applications:
 One interface for the OAMP application.
 Interfaces for Call Control and Media applications, where two of them are IPv4
interfaces and one is an IPv6 interface.
1. IP Interfaces table:
Table 12-10: Example of VoIP Interfaces of Combined Application Types in IP Interfaces table
Inde
x
Applicatio
n Type
Interfac
e Mode
IP Address
Prefix
Lengt
h
Default
Gateway
Etherne
t
Device
Name
0 OAMP IPv4
Manual
192.168.0.2 16 192.168.0.1 1 Mgmt
1 Media &
Control
IPv4
Manual
200.200.85.14 24 200.200.85.
1
201 MediaCntrl1
2 Media &
Control
IPv4
Manual
200.200.86.14 24 200.200.86.
1
202 MediaCntrl2
3 Media &
Control
IPv6
Manual
2000::1:200:200:86:1
4
64 :: 202 V6CntrlMedia
2
2. Static Routes table: A routing rule is required to allow remote management from a
host in 176.85.49.0/24:
Table 12-11: Example of Static Routes Table
Destination Prefix Length Gateway
176.85.49.0 24 192.168.0.10
