Version 7.2 553 Mediant 800B Gateway & E-SBC
User's Manual 24. Routing
2. From the 'Disconnect Call With PI If Alt' drop-down list (DisconnectCallwithPIifAlt),
select the required option:
Figure 24-15: Configuring Alternative Routing upon ISDN Disconnect
3. Click Apply.
24.5.4 Alternative Routing from FXO to IP
You can enable the device to automatically switch the destination of an FXS call from FXO
(PSTN) to IP (SIP Trunk) when the PSTN disconnects the FXS subscriber. When a PSTN
disconnects a subscriber, the device automatically (or manually through TR-104),
recognizes the signal of the call placed by the subscriber and then re-routes the call to a
SIP Trunk. This is configured using the ini file parameter, TR104FXOSwitchover.
For more information on this application, please contact your AudioCodes sales
representative.
