Version 7.2 57 Mediant 800B Gateway & E-SBC
User's Manual 6. Web-Based Management
Item # Description
7
Back and Forward buttons that enable quick-and-easy navigation through previously
opened pages. This is especially useful when you find that you need to return to a
previously accessed page, and then need to go back to the page you just left.
Back button: Goes back to the previously accessed page.
Forward button: Opens the page that you initially left using the back button.
The button is available only if you have used the Back button.
8
Navigation pane, which displays the Navigation tree containing the commands
(items) for opening the configuration pages (see 'Navigation Tree' on page 57).
9
SRD filter. When your configuration includes multiple SRDs, you can filter tables in
the Web interface by a specific SRD. For more information, see 'Filtering Tables in
Web Interface by SRD' on page 353.
10
Search box for searching parameter names and values (see 'Searching for
Configuration Parameters' on page 69).
11
Work pane where configuration pages are displayed.
6.1.4 Accessing Configuration Pages from Navigation Tree
Accessing configuration pages is a three-fold process that consists of selecting a menu on
the menu bar, a tab on the tab bar, and then a page item in the Navigation pane. The
Navigation pane provides the Navigation tree, which is a tree-like structure of folders and
page items that open configuration pages in the Work pane. The hierarchical structure and
organization of the items in the Navigation tree allow you to easily drill-down and locate the
required item.
The Navigation tree consists of the following areas:
Home : (Callout #1) First ("home") page displayed when a menu-tab combination is
initially selected. For example, the home page of the Setup menu - Administration
tab combination is the Time & Date page.
Folders: (Callout #2) Folders group items of similar functionality. To open and close a
folder, simply click the folder name.
