User's Manual 830 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
46.6 Configuring Name for Telephony Ports
You can configure an arbitrary name or a brief description for each telephony port
displayed on the Home page. This description is displayed as a tooltip when you hover
your mouse over the port.
Note: Only alphanumerical characters can be used in the port description.
 To add a port description:
1. Open the Monitor home page (see 'Viewing Device Status on Monitor Page' on page
918).
2. Click the required port icon; a shortcut menu appears:
3. From the shortcut menu, choose Port Description; the following dialog box appears:
Figure 46-2: Configuring Analog Port Description
4. Type a brief description for the port, and then click Submit.
