Version 7.2 995 Mediant 800B Gateway & E-SBC
User's Manual 63. Reporting Information to External Party
3. Configure the following parameters:
• In the 'CDR Server IP Address' field (CDRSyslogServerIP), enter the IP address
of the server to where you want the CDRs sent.From the 'CDR Report Level'
drop-down list (CDRReportLevel), select the stage of the call at which you want
CDRs to be generated and sent.
• (Applicable only to SBC) From the 'Media CDR Report Level' drop-down list
(MediaCDRReportLevel), select the stage of the call at which you want CDRs to
be generated and sent.
• From the 'CDR Syslog Sequence Number' drop-down list (CDRSyslogSeqNum),
enable or disable the inclusion of the sequence number (S=) in CDR Syslog
messages.
4. Click Apply.
Note:
• If you do not configure an IP address for a CDR server, the device sends CDRs to
the Syslog server, as configured in 'Enabling Syslog' on page 1018.
• The device sends CDRs only for dialog-initiating INVITE messages (call start), 200
OK responses (call connect) and BYE messages (call end). For SBC calls only: If
you want to enable the generation of CDRs for non-call SIP dialogs (such as
SUBSCRIBE, OPTIONS, and REGISTER), use the EnableNonCallCdr parameter.
63.2.5 Storing CDRs on the Device
The CDRs of Gateway and SBC calls generated by the device can also be stored locally
on the device (RAM).
Note: When the device is reset or powered off, locally stored CDRs are deleted.
You can specify the calls (configuration entities) for which you wish to create CDRs and
store locally. This is done using Logging Filter rules in the Logging Filters table. For
example, you can configure a rule to create CDRs for traffic belonging only to IP Group 2
and store the CDRs locally.
The locally stored CDRs are saved in a comma-separated values file (*.csv), where each
CDR is shown on a dedicated row. An example of a CSV file with two CDRs are shown
below:
CSV file viewed in Excel:
CSV file viewed in a text editor (Notepad):
Figure 63-11: CSV File of CDRs in Text Editor (Notepad)
To view the CDR column headers corresponding to the CDR data in the CSV file, run the
following CLI command:
