AudioCodes Mediant 800B User Manual

Version 7.2 1021 Mediant 800B Gateway & E-SBC
User's Manual 64. Syslog and Debug Recording
Note:
• You can also view logged user activities in the Web interface (see 'Viewing Web
User Activity Logs' on page 933).
• Logging of CLI commands can only be configured through CLI or ini file.
• You can configure the device to send an SNMP trap each time a user performs a
Web activity. For more information, see 'Configuring SNMP Community Strings' on
page 97.
64.2.6 Viewing Syslog Messages
You can receive and view Syslog messages generated by the device using any of the
following Syslog server types:

Wireshark: Third-party, network protocol analyzer (http://www.wireshark.org).
Note: When debug recording is enabled and Syslog messages are also included in
the debug recording, to view Syslog messages using Wireshark, you must install
AudioCodes' Wireshark plug-in (acsyslog.dll). Once the plug-in is installed, the Syslog
messages are decoded as "AC SYSLOG" and displayed using the "acsyslog" filter
(instead of the regular "syslog" filter). For more information on debug recording, see
'Debug Recording' on page 1022.

Third-party, Syslog Server: Any third-party, Syslog server program that enables
filtering of messages according to parameters such as priority, IP sender address,
time, and date.

Device's CLI Console: The device sends error messages (e.g., Syslog messages) to
the CLI as well as to the configured destination. Use the following commands:
• To start debug recording:
debug log
• To stop debug recording:
no debug log
• To stop all debug recording:
no debug log all

Device's Web Interface: The device provides an embedded Syslog server, which is
accessed through the Web interface (Troubleshoot tab > Troubleshoot menu >
Message Log ). This provides limited Syslog server functionality.
