User's Manual 974 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
CDR Field Range Description
TxRTPssrc
0 to 0xFFFFFFFF Tx RTP SSRC
RxRTPssrc
0 to 0xFFFFFFFF Local RTP SSRC
LocalRFactor
0 to 120 (127 if information is
unavailable)
Local conversation quality
Note: If the RTCP XR feature is
unavailable (not licensed or disabled),
this R-factor VoIP metric is not provided.
Instead, the device sends the CDR field
with the value 127, meaning that
information is unavailable.
RemoteRFactor
0 to 120 (127 if information is
unavailable)
Remote conversation quality
Note: If the RTCP XR feature is
unavailable (not licensed or disabled),
this R-factor VoIP metric is not provided.
Instead, the device sends the CDR field
with the value 127, meaning that
information is unavailable.
LocalMosCQ
10 to 46 (127 if information is
unavailable)
Local MOS for conversation
RemoteMosCQ
10 to 46 (127 if information is
unavailable)
Remote MOS for conversation
TxRTPIPDiffServ
0 to 63 Media IP DiffServ
LatchedRtpIp
Remote IP address of the incoming RTP
stream that the device "latched" on to as
a result of the RTP latching mechanism
for NAT traversal.
LatchedRtpPort
0 to 0xFFFF Remote RTP port of the incoming RTP
stream that the device "latched" on to as
a result of the RTP latching mechanism
for NAT traversal.
LatchedT38Ip
Latching of a new T.38 stream - new IP
address
LatchedT38Port
0 to 0xFFFF Latching of a new T.38 stream - new
port
63.2.1.3 CDR Fields for SBC Local Storage
The CDR fields for SBC calls that are stored locally (history) on the device are listed in the
table below. For storing CDRs locally, see 'Storing CDRs on the Device' on page 995.
Table 63-4: Default CDR Fields for Locally Stored (History) CDRs
CDR Field Title
Report Type SBCReportType
Endpoint Type EPTyp
Call Id SIPCallId
Session ID SessionId
To Next Page
