AudioCodes Mediant 800B User Manual

Version 7.2 973 Mediant 800B Gateway & E-SBC
User's Manual 63. Reporting Information to External Party
CDR Field Range Description
LegId
Unique ID number of the call leg within a
specific call session. The field is
included in all Report Types
(MediaReportType).
A basic call consists of two legs
(incoming leg and outgoing leg) and
thus, two leg IDs are generated for the
session, one for each leg.
For each new call, the device assigns
leg ID "1" to the first leg. The device then
increments the leg ID for subsequent
legs according to the leg sequence in
the call session. For example, the device
generates leg ID "1" for the incoming leg
and leg ID "2" for the outgoing leg. If the
call is transferred, the device generates
leg ID "3" for the leg belonging
to the call
transfer target. Another example is a call
forking session where the leg ID
sequence may be as follows: incoming
leg is "1", outgoing leg to user's office
phone is "2" and outgoing leg to the
user's mobile phone is "3". If the call is
then transferred, the leg ID for the
transfer leg is "4".
Cid
Channel CID
MediaType
Media type (audio, video, or text)
Coder
Coder name
PacketInterval
10 to 200 ms Coder packet interval
LocalRtpIp
Local RTP IP address
LocalRtpPort
0 to 0xFFFF Local RTP port
RemoteRtpIp
Remote RTP IP address
RemoteRtpPort
0 to 0xFFFF Remote RTP port
InPackets
0 to 0xFFFFFFFF Number of packets received by the
device (local)
OutPackets
0 to 0xFFFFFFFF Number of packets sent by the device
(local)
LocalPackLoss
0 to 0xFFFFFFFF Number of packet loss of the entire
stream (local)
RemotePackLoss
0 to 0xFFFFFF (-1 if
information is unavailable)
Remote packet loss
RTPdelay
0 to 10000 ms (-1 if
information is unavailable)
Average RTP delay of the entire stream
RTPjitter
0 to 40000 samples (-1 if
unavailable)
RTP jitter
