Version 7.2 839 Mediant 800B Gateway & E-SBC
User's Manual 47. Auxiliary Files
Resolution: 8-bit
Channels: mono
The prerecorded tones are played repeatedly. This allows you to record only part of the
tone and then play the tone for the full duration. For example, if a tone has a cadence of 2
seconds on and 4 seconds off, the recorded file should contain only these 6 seconds. The
device repeatedly plays this cadence for the configured duration. Similarly, a continuous
tone can be played by repeating only part of it.
47.5 CAS Files
The CAS Auxiliary files contain the CAS Protocol definitions that are used for CAS-
terminated trunks. You can use the supplied files or construct your own files. Up to eight
files can be loaded to the device. Different files can be assigned to different trunks
(CASTableIndex_x) and different CAS tables can be assigned to different B-channels
(CASChannelIndex).
To load CAS files see 'Loading Auxiliary Files' on page 831.
Note: All CAS files loaded together must belong to the same trunk type (i.e., either E1
or T1).
47.6 Dial Plan File
The Dial Plan file can be used for various digit mapping features, as described in this
section.
Note: For the SBC application: The Dial Plan described in this section is for backward
compatibility purposes only. For the new Dial Plan method, see Configuring Dial
Plans on page 751.
47.6.1 Creating a Dial Plan File
Note: For the SBC application: The Dial Plan described in this section is for backward
compatibility purposes only. For the new method, see Configuring Dial Plans on page
751.
The Dial Plan file is a text-based file that can contain up to 8 Dial Plans (Dial Plan indices)
and up to 8,000 rules (lines). The general syntax rules for the Dial Plan file are as follows
(syntax specific to the feature is described in the respective section):
Each Dial Plan index must begin with a Dial Plan name enclosed in square brackets
"[...]" on a new line.
Each line under the Dial Plan index defines a rule.
Empty lines are ignored.
