Version 7.2 921 Mediant 800B Gateway & E-SBC
User's Manual 55. System Status
Item # Description
If you click a port, a shortcut menu appears with commands allowing you to do the
following:
Reset channel (Analog ports only): Resets the analog port (see Resetting an
Analog Channel on page 827)
Port Settings: Displays trunk status (see 'Viewing Trunk and Channel Status' on
page 955) and analog port status (see 'Viewing Port Information' on page 921)
Update Port Info: Assigns a name to the port (see 'Configuring Name for
Telephony Ports' on page 830)
6 Gigabit Ethernet port status icons:
(green): Link is working
(gray): Link is not configured
(red): Link error
To view detailed port information, click the port icon (see Viewing Ethernet Port
Information on page 959).
7 Fast Ethernet port status icons. See Item 6 for a description.
55.2.1 Viewing Port Information
You can view detailed information per port. The information is grouped under the following
tabs:
SIP: Displays SIP-related information such as endpoint status (e.g., idle) and phone
number
Basic: Displays information such as call duration, line voltage, hook status (off or on),
and polarity reversal.
RTP/RTCP: Displays RTP/RTCP-related information such as packet loss and network
jitter.
Voice Settings: Displays voice-related configuration such as silence suppression.
To view information on an analog port:
1. Open the Monitor home page (see 'Viewing Device Status on Monitor Page' on page
918).
2. On the graphical display of the device, click a port; a shortcut menu appears.
3. From the shortcut menu, choose Port Status.
• For digital ports: The Trunks & Channel Status page appears (see Viewing Trunk
and Channel Status on page 955). Click a channel; the following page appears
with the Basic tab selected:
