User's Manual 1034 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
Line Voltage (V)
Hook (0 = on-hook; 1 = off-hook)
Ring (0 - Off; 1 - On)
Line Connected (0 = Disconnected; 1 = Connected)
Polarity state (0 = Normal; 1 = Reversed, 2 = N\A)
Line polarity (0 = Positive; 1 = Negative)
Message Waiting Indication (0 = Off; 1 = On)
You can also view the above information through the Web interface (see 'Viewing Port
Information' on page 921).
Note:
Analog line testing is traffic affecting and therefore, do the test only for
monitoring and when there are no active calls in progress.
