Version 7.2 143 Mediant 800B Gateway & E-SBC
User's Manual 12. Network
By default, the device provides a pre-configured Ethernet Device at Index 0 with the
following settings:
Name: "vlan 1"
VLAN ID: 1
Ethernet Group: GROUP 1
Tagging Policy: Untagged
MTU: 1500
The pre-configured Ethernet Device is associated with the default IP network interface (ie.,
OAMP) in the IP Interfaces table. The Untagged policy of the pre-configured Ethernet
Device enables you to connect to the device using the default OAMP interface.
You can view configured Ethernet Devices that have been successfully applied to the
device (saved to flash) in the Ethernet Device Status table. This page is accessed by
clicking the Ethernet Device Status Table button located at the bottom of the Ethernet
Devices table. The Ethernet Device Status table can also be accessed from the Navigation
tree (see 'Viewing Ethernet Device Status' on page 959).
Note: You cannot delete an Ethernet Device that is associated with an IP network
interface (in the IP Interfaces tabl
e). You can only delete it once you have
disassociated it from the IP network interface.
The following procedure describes how to configure Ethernet Devices through the Web
interface. You can also configure it through ini file (DeviceTable) or CLI (configure network
> network-dev).
To configure an Ethernet Device:
1. Open the Ethernet Devices table (Setup menu > IP Network tab > Core Entities
folder > Ethernet Devices).
2. Click New; the following dialog box appears:
3. Configure an Ethernet Device according to the parameters described in the table
below.
4. Click Apply.
