AudioCodes Mediant 800B - Page 183

Version 7.2 183 Mediant 800B Gateway & E-SBC
User's Manual 13. Security
 To configure an IDS Policy:
1. Open the IDS Policies table (Setup menu > Signaling & Media tab > Intrusion
Detection folder > IDS Policies); the table displays the pre-configured IDS policies:
Figure 13-3: IDS Policies Table with Default Rules
2. Click New; the following dialog box appears:
Figure 13-4: IDS Policies Table - Add Dialog Box
3. Configure an IDS Policy name according to the parameters described in the table
below.
4. Click Apply.
Table 13-3: IDS Policies Table Parameter Descriptions
Parameter Description
Index
policy
[IDSPolicy_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
rule
[IDSPolicy_Name]
Defines a descriptive name, which is used when associating the row
in other tables.
The valid value is a string of up to 40 characters.
Description
description
[IDSPolicy_Description]
Defines a brief description for the IDS Policy.
The valid value is a string of up to 100 characters.
5. In the IDS Policies table, select the required IDS Policy row, and then click the IDS
Rule link located below the table; the IDS Rule table opens.
