Version 7.2 257 Mediant 800B Gateway & E-SBC
User's Manual 15. Services
2. Click New; the following dialog box appears:
Figure 15-21: LDAP Server Groups Table - Add Dialog Box
3. Configure an LDAP Server Group according to the parameters described in the table
below.
4. Click Apply.
Table 15-8: LDAP Server Groups Table Parameter Descriptions
Parameter Description
General
Index
[LdapServerGroups_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
name
[LdapServerGroups_Name]
Defines a descriptive name, which is used when associating
the row in other tables.
The valid value is a string of up to 20 characters.
Note: Each row must be configured with a unique name.
Type
server-type
[LdapServerGroups_ServerType]
Defines whether the servers in the group are used for SIP-
related LDAP queries (Control) or management login
authentication-related LDAP queries (Management).
 [0] Control (Default)
 [1] Management
Note: Only one LDAP Server Group can be defined for
management.
Server Search Method
server-search-method
[LdapServerGroups_SearchMethod
]
Defines the method for querying between the two LDAP
servers in the group.
 [0] Parallel = (Default) The device queries the LDAP servers
at the same time.
 [1] Sequential = The device first queries one of the LDAP
servers and if the DN object is not found or the search fails,
it queries the second LDAP server.
