User's Manual 304 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
 To configure an HTTP Proxy Host:
1. Open the HTTP Proxy Services table (Setup menu > IP Network tab > HTTP Proxy folder >
HTTP Proxy Services).
2. In the table, select the required HTTP Proxy Service index row, and then click the HTTP
Proxy Hosts link located below the table; the HTTP Proxy Hosts table appears.
3. Click New; the following dialog box appears:
Figure 15-54: HTTP Proxy Hosts Table - Add Dialog Box
4. Configure an HTTP Proxy Host according to the parameters described in the table below.
5. Click Apply, and then save your settings to flash memory.
Table 15-23: HTTP Proxy Hosts Table Parameter Descriptions
Parameter Description
General
Index
Defines an index number for the new table row.
Note:
 Each row must be configured with a unique index.
 The parameter is mandatory.
Network Interface
network-interface
[HTTPProxyHost_NetworkInterface]
Assigns a local, network interface to the HTTP Proxy Host.
By default, no value is defined.
To configure network interfaces, see 'Configuring IP Network
Interfaces' on page 146.
Note: The parameter is mandatory.
Proxy Address
proxy-address
[HTTPProxyHost_IpAddress]
Defines the address of the managed equipment (host).
The valid value is an IP address in dotted-decimal notation or an
FQDN (up to 100 characters). If the address is an FQDN, the device
uses DNS to resolve it into an IP address. If the DNS resolution
results in multiple IP addresses, the device uses the first available
address (i.e., that responds to the keep-alive).
Protocol
protocol
[HTTPProxyHost_Protocol]
Defines the protocol type.
 [0] HTTP (default)
 [1] HTTPS
HTTP Port
http-port
[HTTPProxyHost_Port]
Defines the port of the managed equipment.
The default is 0.
Note: The parameter is mandatory.
