User's Manual 344 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
3. Click New; the following dialog box appears:
Figure 17-3: Remote Media Subnet Table - Add Dialog Box
4. Configure the Remote Media Subnet according to the parameters described in the
table below.
5. Click Apply.
Table 17-2: Remote Media Subnet Table Parameter Descriptions
Parameter Description
Index
[RemoteMediaSubnet_RemoteMediaSubnetIndex]
Defines an index number for the new table row.
Note: Each row must be configured with a
unique index.
Name
name
[RemoteMediaSubnet_RemoteMediaSubnetName]
Defines a descriptive name, which is used when
associating the row in other tables.
The valid value is a string of up to 20 characters.
Note: Each row must be configured with a
unique name.
Prefix Length
prefix-length
[RemoteMediaSubnet_PrefixLength]
Defines the subnet mask in Classless Inter-
Domain Routing (CIDR) notation. For example,
16 denotes 255.255.0.0.
The default is 16.
Address Family
address-family
[RemoteMediaSubnet_AddressFamily]
Defines the IP address protocol.
 [2] IPv4 (default)
 [10] IPv6
Destination IP
dst-ip-address
[RemoteMediaSubnet_DstIPAddress]
Defines the IP address of the destination.
The default is 0.0.0.0.
