User's Manual 474 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
To configure a Tel Profile:
1. Open the Tel Profiles table (Setup menu > Signaling & Media tab > Coders &
Profiles folder > Tel Profiles).
2. Click New; the following dialog box appears:
Figure 20-9: Tel Profiles Table - Add Dialog Box
3. Configure a Tel Profile according to the parameters described in the table below. For a
description of each parameter, refer to the corresponding "global" parameter.
4. Click Apply.
Table 20-6: Tel Profile Table Parameters and Corresponding Global Parameters
Tel Profile Parameter Global Parameter
General
Index
[TelProfile_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
profile-name
[TelProfile_ProfileName]
Defines a descriptive name, which is used when associating the row in other
tables.
The valid value is a string of up to 40 characters.
Signaling
Profile Preference
tel-preference
[TelProfile_TelPreference]
Defines the priority of the Tel Profile, where 1 is the lowest priority and 20 the
highest priority.
Note:
If both the IP Profile and Tel Profile apply to the same call,
the coders and common parameters of the Preferred profile
are applied to the call.
If the Preference of the Tel Profile and IP Profile are
identical, the Tel Profile parameters are applied.
If the coder lists of both the IP Profile and Tel Profile apply
to the same call, only the coders common to both are used.
The order of the coders is determined by the preference.
Fax Signaling Method
Defines the SIP signaling method for establishing and
