User's Manual 536 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
The following procedure describes how to configure IP-to-Tel routing rules through the
Web interface. You can also configure it through ini file (PSTNPrefix) or CLI (configure voip
> gateway routing ip2tel-routing).
To configure IP-to-Tel routing rules:
1. Open the IP-to-Tel Routing table (Setup menu > Signaling & Media tab > Gateway
folder > Routing > IP > Tel Routing).
2. Click New; the following dialog box appears:
Figure 24-3: IP-to-Tel Routng Table - Add Dialog Box
3. Configure a routing rule according to the parameters described in the table below.
4. Click Apply.
The following table shows configuration examples of Tel-to-IP routing rules:
Table 24-3: Example of IP-to-Tel Routing Rules
Parameter Rule 1 Rule 2 Rule 3
Source Host Prefix
abcd.domain
Destination Phone Prefix 1x [501-502]
Source Phone Prefix
101
Source IP Address
Trunk Group ID 3 2 4
IP Profile ITSP-A ITSP-B
Below provides descriptions of each rule:
Rule 1: If the incoming IP call destination phone prefix is between 10 and 19, the call
is assigned settings configured for IP Profile "ITSP-A" and routed to Trunk Group ID 3.
Rule 2: If the incoming IP call destination phone prefix is between 501 and 502 and
source phone prefix is 101, the call is assigned settings configured for IP Profile
"ITSP-B" and routed to Trunk Group ID 2.
