Version 7.2 567 Mediant 800B Gateway & E-SBC
User's Manual 25. Manipulation
The following procedure describes how to configure redirect number manipulation rules
through the Web interface. You can also configure these rules using the following
management tools:
Redirect Number IP to Tel table: ini file (RedirectNumberMapIp2Tel) or CLI (configure
voip > gateway manipulation redirect-number-map-ip2tel)
Redirect Number Tel to IP table: ini file (RedirectNumberMapTel2Ip) or CLI (configure
voip > gateway manipulation redirect-number-map-tel2ip)
To configure a redirect number manipulation rule:
1. Open the required redirect number manipulation table (Setup menu > Signaling &
Media tab > Gateway folder > Manipulation > Redirect Number Tel > IP or Redirect
Number IP > Tel).
2. Click New; the following dialog box appears (e.g., Redirect Number Tel-to-IP table):
Figure 25-4: Redirect Number Manipulation for Tel-to-IP Table (Example) - Add Dialog Box
3. Configure a manipulation rule according to the parameters described in the table
below.
4. Click Apply.
Table 25-5: Redirect Number Manipulation Tables Parameter Description
Parameter Description
General
Index
[_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
manipulation-name
[_ManipulationName]
Defines a descriptive name, which is used when associating the row in
other tables.
The valid value is a string of up to 40 characters.
Match
