2. Select the row corresponding to the port that you want to configure, and then click
Edit; the following dialog box appears:
Figure 28-6: Call Forward Table - Edit Dialog Box
3. Configure call forwarding per port according to the parameters described in the table
below.
4. Click Apply.
Table 28-4: Call Forward Table Parameter Descriptions
Parameter Description
General
Index
[FwdInfo_Index]
(Read-only) Displays the index number of the table row.
Module
[FwdInfo_Module]
(Read-only) Displays the module number on which the port is located.
Port
[FwdInfo_Port]
(Read-only) Displays the port number.
Port Type
[FwdInfo_PortType]
(Read-only) Displays the port type (FXS or FXO).
Type
type
[FwdInfo_Type]
Defines the condition upon which the call is forwarded.
[0] Deactivate = (Default) Don't forward incoming calls.
[1] On Busy = Forward incoming calls when the port is busy.
[2] Unconditional = Always forward incoming calls.
[3] No Answer = Forward incoming calls that are not answered within
the time specified in the 'No Reply Time' field.
[4] On Busy or No Answer = Forward incoming calls when the port is
busy or when calls are not answered within the time specified in the
'No Reply Time' field.
[5] Don't Disturb = Immediately reject incoming calls.
Call Forward
Forward Destination
destination
Defines the telephone number or URI (<number>@<IP address>) to
where the call is forwarded.
