User's Manual 718 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
Parameter Description
together with the 'Call Trigger' parameter (in the table).
The default is Any (i.e., any IP Group).
Note: The selectable IP Group for the parameter depends on the
assigned Routing Policy (in the 'Routing Policy' parameter in this
table). For more information, see 'Configuring SBC Routing
Policy Rules' on page 730.
Action
Destination Type
dst-type
[IP2IPRouting_DestType]
Determines the destination type to which the outgoing SIP dialog
is sent.
 [0]
IP Group = (Default) The SIP dialog is sent to the IP Group
as defined in the 'Destination IP Group'
(IP2IPRouting_DestIPGroupName) parameter. For more
information on the actual address, see the 'Destination IP
Group' parameter.
 [1] Dest Address = The SIP dialog is sent to the address
configured in the following parameters: 'Destination Address',
'Destination Port' and 'Destination Transport Type'.
 [2] Request URI = The SIP dialog is sent to the address
indicated in the incoming Request-URI. If the parameters
'Destination Port' and 'Destination Transport Type' are
configured, the incoming Request-URI parameters are
overridden and these parameters take precedence.
 [3] ENUM = An ENUM query is sent to include the destination
address. If the parameters 'Destination Port' and 'Destination
Transport Type' are configured, the incoming Request-URI
parameters are overridden and these parameters take
precedence.
 [4] Hunt Group = Used for call center survivability. For more
information, see 'Configuring Call Survivability for Call
Centers' on page 785.
 [5] Dial Plan = (For Backward Compatibility Only - see
Note below) The IP destination is determined by a Dial Plan
index of the loaded Dial Plan file. The syntax of the Dial Plan
index in the Dial Plan file is as follows: <destination / called
prefix number>,0,<IP destination>
Note that the second parameter "0" is ignored. An example of
a configured Dial Plan (# 6) in the Dial Plan file is shown
below:
[ PLAN6 ]
200,0,10.33.8.52 ; called prefix 200 is
routed to destination 10.33.8.52
201,0,10.33.8.52
300,0,itsp.com ; called prefix 300 is
routed to destination itsp.com
Once the Dial Plan is defined, you need to assign it (0 to 7) to
the routing rule as the destination in the 'Destination Address'
parameter, where "0" denotes [PLAN1], "1" denotes [PLAN2],
and so on.
 [7] LDAP = LDAP-based routing. Make sure that the Routing
Policy assigned to the routing rule is configured with the LDAP
Server Group for defining the LDAP server(s) to query.
 [8] Gateway = The device routes the SBC call to the Tel side
