Version 7.2 925 Mediant 800B Gateway & E-SBC
User's Manual 55. System Status
Tab Field Description
RTP Direction Direction of RTP:
 "Tx & Rx": both directions (transmit and
receive)
Local UDP Port Local UDP port on the device.
Remote IP Addr IP address of the remote IP side.
Remote UDP Port Port of the remote IP side.
Rx Octet Count Total number of received packets.
Tx Octet Count Total number of transmitted packets.
Network Jitter Network jitter (in msec).
Roundtrip Delay Round-trip delay time (in msec).
Packet Loss Packet loss (in %).
Remote RTCP CName RTP Control Protocol (RTCP) Canonical Name
(CNAME) - persistent transport-level identifier for
an RTP endpoint.
Voice
Settings
Channel Identifier Channel ID.
Coder Displays the coder used for the call.
Frame Duration Frame duration (in msec).
Echo Canceller Indicates whether the echo canceller is enabled or
disabled.
Silence Suppression Indicates whether silence suppression is enabled
or disabled.
Input Gain Displays the volume gain (in dB).
Voice Volume Displays the voice volume gain (in dB).
DTMF Transport Type Displays the DTMF transport type.
Enabled Detectors Displays enabled detectors (e.g., AMD).
Fax Transport Type Displays the fax transport type.
