ĺ <Canceling jobs...> appears, and the print data being processed is canceled.

When <Ready to print.> appears, the job cancellation completes.

IMPORTANT

While <Canceling jobs...> is displayed

You cannot operate the printer.

㻝㻤㻞㻌㻛㻌㻥㻣㻜
