Canon LBP6780x - Removing SD Card

To Next Page

To Previous Page

0978-02H

NOTE

How to remove the cover

For details on how to remove/attach the SD card slot cover, see "Installing SD Card."

Insert the SD card until it clicks, and then release your hand.

Remove the SD card.

Removing SD Card

㻝㻞㻤㻌㻛㻌㻥㻣㻜
