Part Name
Front View
NOTE
About the film attached to the control panel
Remove it before using the panel.
(1) Output Tray (4) Ventilation Slot (7) USB Memory Slot (10) Multi-purpose Tray
(2) Auxiliary Tray
(5) Lift Handle (8) Control Panel (11) Lock Release Switch
(3) Front Cover
(6) Paper Drawer (9) Open Button (12) Duplex Print Transport Guide
Rear View
Names and Dimensions of Each Part
