Canon LBP6780x - Page 796

To Next Page

To Previous Page

Confirm the information on the install confirmation page, and then click [Yes].

When the [License Agreement] appears, confirm the information, and then click [I Accept].

ĺ The installation begins.

㻣㻥㻢㻌㻛㻌㻥㻣㻜
