Step 6 switch(config-zone)# zone commit vsan 1
Commits zoning changes to the selected VSAN.
Disabling Smart Zoning at Zone Level Using Fabric Manager
To broadcast frames in the basic zoning mode using Fabric Manager, follow these steps:
Step 1 Expand a VSAN and then select a zone set in the Logical Domains pane.
Step 2 Click the Policies tab in the Information pane.
You see the Zone policy information in the Information pane.
Figure 41: Zone Policy Information
Step 3 Check the Broadcast check box to enable broadcast frames on the default zone.
Step 4 Click Apply Changes to save these changes.
About LUN Zoning
Logical unit number (LUN) zoning is a feature specific to switches in the Cisco MDS 9000 Series.
LUN zoning can only be implemented in Cisco MDS 9000 Series switches. If LUN zoning is implemented
in a switch, you cannot configure the interop mode in that switch.
Caution
A storage device can have multiple LUNs behind it. If the device port is part of a zone, a member of the zone
can access any LUN in the device. With LUN zoning, you can restrict access to specific LUNs associated
with a device.
When LUN 0 is not included within a zone, then, as per standards requirements, control traffic to LUN 0 (for
example, REPORT_LUNS, INQUIRY) is supported, but data traffic to LUN 0 (for example, READ, WRITE)
is denied.
Note
• Host H1 can access LUN 2 in S1 and LUN 0 in S2. It cannot access any other LUNs in S1 or S2.
Cisco MDS 9000 Series Fabric Configuration Guide, Release 8.x
100
Configuring and Managing Zones
Disabling Smart Zoning at Zone Level Using Fabric Manager
