Cisco MDS 9000 Series Configuration Guide

Example:
IPv6 address example:
Example:
switch(config-fcalias)# member ipv6-address 2001::db8:800:200c:417a/64
Example:
Local sWWN interface example:
Example:
switch(config-fcalias)# member interface fc 2/1
Example:
Remote sWWN interface example:
Example:
switch(config-fcalias)# member interface fc2/1 swwn 20:00:00:05:30:00:4a:de
Example:
Domain ID interface example:
Example:
switch(config-fcalias)# member interface fc2/1 domain-id 25
Configures a member for the specified fcalias (AliasSample) based on the type (pWWN, fabric pWWN, FC ID, domain
ID, IPv4 address, IPv6 address, or interface) and value specified.
Multiple members can be specified on multiple lines.
Note
Creating FC Aliases Using Fabric Manager
To create an FC alias using Fabric Manager, follow these steps:
Step 1 Choose Zone > Edit Local Full Zone Database.
You see the Select VSAN dialog box.
Step 2 Select a VSAN and click OK.
You see the Edit Local Full Zone Database dialog box for the selected VSAN.
Step 3 Click Aliases in the lower left pane (see Figure 24: Creating an FC Alias, on page 71). The right pane lists the existing
aliases.
Cisco MDS 9000 Series Fabric Configuration Guide, Release 8.x
70
Configuring and Managing Zones
Creating FC Aliases Using Fabric Manager

Cisco MDS 9000 Series Specifications

General

Category	Switch
Operating System	Cisco NX-OS
Ports	Varies by model
Protocols	Fibre Channel (FC), Fibre Channel over IP (FCIP), iSCSI
Redundancy	Redundant supervisors, power supplies, and fans
Management	Cisco Data Center Network Manager (DCNM), CLI, SNMP
Virtualization Support	VSANs (Virtual SANs)
Security Features	Fibre Channel Security Protocol (FC-SP)
Hot Swappable Components	power supplies, fans
Power Supply Options	AC and DC options available
