Cisco MDS 9000 Series

Figure 24: Creating an FC Alias
Step 4 Click the Insert icon to create an alias.
You see the Create Alias dialog box (see Figure 25: Create Alias Dialog Box, on page 71).
Figure 25: Create Alias Dialog Box
Step 5 Set the Alias Name and the pWWN.
Step 6 Click OK to create the alias.
Adding Members to Aliases
To add a member to an alias using Fabric Manager, follow these steps:
Step 1 Choose Zone > Edit Local Full Zone Database.
You see the Select VSAN dialog box.
Step 2 Select a VSAN and click OK.
You see the Edit Local Full Zone Database dialog box for the selected VSAN (see Figure 26: Edit Local Full Zone
Database Dialog Box, on page 72).
Cisco MDS 9000 Series Fabric Configuration Guide, Release 8.x
71
Configuring and Managing Zones
Adding Members to Aliases
