switch(config-zoneset-zone)#
Adds a zone (InlineZone1) to the specified zoneset (Zoneset1).
Execute this step only if you need to create a zone from a zoneset prompt.
Tip
Step 5 switch(config-zoneset-zone)# member fcid 0x111112
Example:
switch(config-zoneset-zone)#
Adds a new member (FC ID 0x111112) to the new zone (InlineZone1).
Execute this step only if you need to add a member to a zone from a zoneset prompt.
Tip
Filtering Zones, Zone Sets, and Device Aliases Based on Name
To filter the zones, zone sets or device aliases, follow these steps:
Step 1 Click the Zone icon in the toolbar (see Figure 12: Zone Icon, on page 57).
Step 2 Enter a filter condition, such as *zo1*, in the Filter text box.
Step 3 Click Go.
Adding Multiple Zones to Multiple Zone Sets
To add multiple zones to multiple zone sets, follow these steps:
Step 1 Click the Zone icon in the toolbar (see Figure 12: Zone Icon, on page 57).
Step 2 From the tree view, select Zoneset.
Step 3 Use the Ctrl key to select multiple end devices.
Step 4 Right-click and then select Add to Zoneset.
Step 5 Use the Ctrl key to select multiple zones from the pop-up window displayed.
Step 6 Click Add.
Selected zones are added to the selected zone sets.
Zone Enforcement
Zoning can be enforced in two ways: soft and hard. Each end device (N port or NL port) discovers other
devices in the fabric by querying the name server. When a device logs in to the name server, the name server
Cisco MDS 9000 Series Fabric Configuration Guide, Release 8.x
75
Configuring and Managing Zones
Filtering Zones, Zone Sets, and Device Aliases Based on Name
